Industrial Washing | Front Load

Front Loading Washing Machines

Front-load open-pocket washing machines for repeatable wash quality and easy commercial loading.

Capacity15 kg to 120 kg
HeatingElectric, steam or thermal fluid
MaterialSS front, basket, drum and hopper
Power415 V, 3 phase, 50 Hz

Technical specifications and selection details.

Use these indicative details to shortlist the right configuration. Final dimensions, power load, heating arrangement and model selection should be confirmed with Raj Sons before order.

15 kg25 kg30 kg50 kg60 kg120 kg

Buyer Checklist

  • Fabric type
  • Water per fill
  • Door access space
  • Heating source

Features & Benefits

  • Large toughened-glass loading door with safety stop
  • Auto timed, auto reverse and forward cycles
  • Auto digital temperature and water level control
  • Highly polished stainless steel inner basket and outer drum
  • Electric, steam or thermal fluid heating options

Industrial Applications

  • Hospitality linen
  • Healthcare laundry
  • Garment washing
  • Dry-cleaning plants
  • Service laundries

Product Guidance

Front loading washing machine use and configuration guidance.

Front loading washing machines are useful for commercial wash rooms that need straightforward loading, repeatable wash action and clear operator visibility through a toughened glass door. The open-pocket format suits fabric, linen and garment batches where controlled washing is more important than very high final extraction. Raj Sons offers these machines for hospitality linen, healthcare laundry, dry-cleaning plants and service laundries that run varied daily loads.

The right model depends on batch size, water per fill, wash program expectations and the heating source available at site. Smaller capacities can support boutique laundry or garment care work, while larger options are better for hotels, hospitals and commercial operators with predictable daily linen flow. Installation planning should include door swing, operator aisle width, inlet pressure, drain line size and safe electrical isolation.

For a faster quote, share expected daily load, site city, preferred capacity, available utilities and current workflow for Front Loading Washing Machines. Raj Sons can compare options such as 15 kg, 25 kg, 30 kg, 50 kg for applications like Hospitality linen, Healthcare laundry, Garment washing and suggest whether the priority should be throughput, finish quality, compact footprint, lower heating load or process flexibility.

Planning Notes

  • Choose the capacity around the heaviest regular batch rather than an occasional peak load.
  • Review fabric categories because towels, sheets, uniforms and garments need different water and cycle planning.
  • Confirm whether electric, steam or thermal fluid heating is easier to maintain at the installation site.
  • Allow clear front access for loading, unloading, cleaning and routine inspection of the door seal.

Specification table

Model RangeRS-FL Series
Capacity Options15 kg, 25 kg, 30 kg, 50 kg, 60 kg, 120 kg
Operating Voltage415 V +-10%
Loading TypeFront loading
Wash SpeedApprox. 35 RPM
Extract SpeedApprox. 200 RPM
Basket Volume RangeApprox. 181 L to 1475 L
Wash Motor RangeApprox. 0.75 kW to 3.75 kW
Heating OptionsElectric, steam or thermal fluid

Specifications are indicative and may vary by machine model, customization and utility conditions.

Quote Support

Share capacity, address and application for Front Loading Washing Machines.

Raj Sons will help shortlist suitable machinery for hotels, hospitals, commercial laundries, garment units, textile workflows and individual machinery buyers.
